DETAILS |
Item | Description |
Frame: | 57cm, silver. All of the tubing is Reynolds 531, except some of the stays, which are 525 because Reynolds stopped making them in 531. The dimensions are spec'd by Waterford, many of them custom.
The spec's are:
Head tube: 31.6 od, 0.8 wall
Top tube: 28.6 od, .8/.6/.8 wall
Down tube: 31.8 od, .9/.6/.9 wall
Seat tube: 28.6 od, .6/.8 wall
Seat stays: 14/16/12.5 od, .7 wall
Chainstays: 22.2/12 od, .8 wall
Fork blades: 23.8/12.4 od, 1.0 wall (round blades)
Size: 57cm
Head: 72 degrees
Seat: 72 degrees
Rake: 5 degrees
BB Drop: 8cm
Chain Stay: 45.5cm
TT: 57cm
Horizontal drops.
Info from orignal owner Ted Durant (first Heron Bicycle Company owner). |
Crankset/Chain rings: | Sugino XD-500 (48/36/26) 170mm 110/74 mm BCD |
BB/Crank Axle: | SunTour GG |
Freewheel: | Sachs Aris 7spd 13-32 (13 15 18 21 24 28 32) |
Chain: | Sachs P51 |
Front derailleur: | ST XC Pro |
Rear derailleur: | ST XC Pro long cage |
Shifters: | ST barcon friction |
Pedals: | Lyotard rat trap pedals |
Brakes: | Front: ST XC Pro cantilevers + Koolstop Eagle Claw pads |
| Rear: ST XC Pro + Koolstop Eagle Claw pads |
Brake levers: | Dia Compe Royals |
Handlebars: | Nitto 46cm |
Bar Tape: | Cotton (black) with rubber padding underneath |
Stem: | SR 10cm reach, 100mm height |
Headset: | SunTour GG |
Tires (28-45 - 622): | Specialized Crossroads EX 700x38 |
Rims: | Mavic T217 silver 700c (470g) 22mm width; 25-40mm tire width; front 40, rear 48h |
Spokes: |
14g DT Stainless 2mm Spokes (Fritz-built touring wheels) |
Rear hub: | Phil 48h 130mm/7spd |
Front hub: | Phil 40h 100mm |
Quick release skewers: | 1/4" allen front, QR rear |
Saddle: | Brooks B17 (with Carradice cover) |
Seatpost: | Kalloy UNO 27.2 |
Cables/Housing: | Black |
Computer | None |
Cages (3): | Blackburn |
Fenders: | SKS (formerly ESGE) Chromoplastic wide (P45) 700c mudguards, with custom mudflaps (currently taken off). |
Racks: | Steel front rack; Blackburn FL-1 Front Lowriders, Rear Expedition Rack when touring. |
Mojo: | Terrapin turtle...recently retired... |
